Raceworks have spent years developing a comprehensive range of performance injectors, building on the foundation of OE Quality brands such as Bosch, Denso and Siemens VDO. Raceworks Fuel Injectors now set the industry standard for quality and reliability, with a variety of flow rates, physical sizes, and fuel compatibility ranging from pump fuel to E85 and Methanol. A full range of connector plug adapters and extensions are also available, enabling a quick and simple upgrade to almost any application.
1000cc Raceworks 3/4 Length – INJ-154
Specifications | Part Number |
---|---|
Size: 1000cc (95 Lb/hr) @ 3bar Impedance: High (12.1Ohms), Plug: USCAR, Top O-Ring: 14mm, E85 Safe Spray Pattern: Pencil Spray Direction: Straight | INJ-154 |
1000cc Raceworks Full Length – INJ-292
Specifications | Part Number |
---|---|
Size: 1000cc (95 Lb/hr) @ 3bar Impedance: High (12.1Ohms), Plug: USCAR, Top O-Ring: 14mm, E85 Safe Spray Pattern: Pencil Spray Direction: Straight | INJ-292 |
1150cc Raceworks 3/4 Length – INJ-285

Specifications | Part Number |
---|---|
Size: 1150cc (110 Lb/hr) @ 3bar and 1300cc (124 Lb/hr) @ 4bar, Impedance: High (12.5Ohms), Plug: Bosch Jetronic/Minitimer, O-Ring: 14mm, E85 Safe Spray Pattern: Pencil Spray Direction: Straight | INJ-285 |
1150cc Raceworks Short w/ Extended Nose – INJ-286
Specifications | Part Number |
---|---|
Size: 1150cc (110 Lb/hr) @ 3bar and 1300cc (124 Lb/hr) @ 4bar, Impedance: High (12.5Ohms), Plug: Bosch Jetronic/Minitimer, O-Ring: 14mm, E85 Safe Spray Pattern: Pencil Spray Direction: Straight | INJ-286 |
1650cc Bosch Motorsport Short – INJ-223
Specifications | Part Number |
---|---|
Size: 1550cc (148Lb/hr) @ 3bar and 1650cc (157Lb/hr) @ 4bar, Impedance: High (8.4Ohms), Plug: Bosch Jetronic/Minitimer, Top O-Ring: 14mm, E85 Safe Spray Pattern: Pencil Spray Direction: Straight | INJ-223 |
2200cc Bosch Short – INJ-139
Specifications | Part Number |
---|---|
Size: 2200cc (209Lb/hr) @ 3bar, Impedance: High (8.8Ohms), Plug: Denso, Top O-Ring: 14mm. Spray Pattern: Wide Cone Spray Direction: Straight | INJ-139 |
